Detail Rubber Tyred Gantry Cranes
Rubber-Tyred Gantry Cranes ( RTG) Space-saving container stacking Mobile for flexible use Capacities : Handling 20’ to 45’ containers Lift capacity ( under spreader) up to 60 t, single/ twinlift Dimensions : Span up to 26.5 m, 7+ 1 truck line Lifting height ( under heavy lift beam) up to 21 m, 6+ 1 high cube box Speeds : Gantry travel 135 m/ min Trolley travel up to 75 m/ min Hoisting with load up to 30 m/ min Design : Fully electric drive; energy-saving system available Power supply: port mains or on-board diesel generator
Silahkan hubungi kami: Gian Ezra atau Rheni Mobile: 0812-9061-8563 atau WA: 0877-8303-2100
Email: sales@partpediaindonesia.com
